Circuit Analysis with PSpice

About This Book

Electrical circuits and electronic circuit accessories are located in all electrical and electronic equipment including household equipment, lighting, heating, air conditioning, home control systems, and commercial buildings alike, computers, consumer electronics, and transport means such as cars, buses, trains, ships, And aircraft. Electrical circuit analysis is essential for the design of all these systems.

Contents

• Chapter 1: Preliminaries to Circuit Analysis
• Chapter 2: Fundamentals of Resistive Circuits
• Chapter 3: Circuit Equivalence
• Chapter 4: Circuit Theorems
• Chapter 5: Circuit Simplification
• Chapter 6: Circuit Equations
• Chapter 7: Capacitors, Inductors, and Duality
• Chapter 8: Sinusoidal Steady State
• Chapter 9: Linear Transformer
• Chapter 10: Ideal Transformers
• Chapter 11: Basic Responses of First-Order Circuits
• Chapter 12: Basic Responses of Second-Order Circuits
• Chapter 13: Ideal Operational Amplifier
• Chapter 14: Frequency Responses
• Chapter 15: Butterworth and Active Filters
• Chapter 16: Responses to Periodic Inputs
• Chapter 17: Real, Reactive, and Complex Power
• Chapter 18: Responses to Step and Impulse Inputs
• Chapter 19: Switched Circuits with Initial Energy Storage
• Chapter 20: Convolution
• Chapter 21: Properties of the Laplace Transform
• Chapter 22: Laplace Transform in Circuit Analysis
• Chapter 23: Fourier Transform
• Chapter 24: Two-Port Circuits
• Chapter 25: Balanced Three-Phase Systems

Source Links

• https://amzn.to/4fAqSCG
